1-ROW, 2-ROW, 3-ROW, 4-ROW, 5-ROW, 6-ROW
ECONOMY NO TILL MAIZE PLANTER

The Piket Economy No Till Maize Planter was designed for planting different crops on smaller farms making use of tractor traction. It was designed to use as a No Till planter, meaning that no soil tillage is required before planting. Seed & fertiliser are planted from a single row up to six rows (depending on the amount of units being used).

Click here to download PDF...

1.8 m, 2.3 m, 2.8 m
FINE SEED PLANTER

• Planting fine seeds (lucern, teff, rye grass, smuts finger, medics, canola)

• Planting larger seeds (wheat, oats, soya beans, lupine, etc.)

• Application of fertiliser together with seed
• Planting on pre-tilled fields
• Two adjustable, interchangeable seed bins
• Double compartment seed bin with individual calibration
• The 1.8 m, 2.3 m and 2.8 m Piket fine seed planter's components can be customised to fit your needs and preferences (T&C's apply)
• Different compaction rollers available for different applications
• NOW WITH RETRACTABLE TINES


No Till or Conventional
14-ROW, 20-ROW
FINE SEED PLANTER

• Very popular on cattle and dairy farms.

• No Till - or conventional. Planting in established pastures.

• Planting of grazing and fine seed crops (teff, lucerne, rye-grass, smuts finger, medics)

• Planting of grain crops (wheat, oats, lupine, etc.)

• Fertiliser (granular) application with seed.


NO TILL DRILL

• No Till. Plants into established pastures
• Cuts through thick stubble
• Proof agains blockages
• Consist of double-disc openers and single disc coulters
• Every unit has the ability of individual depth control
• Three compartment seed bin with individual calibration
• Low compaction wheels
• Robust and strong

Click here to download PDF...

Click here to view a demonstration video...

No Till or Conventional
8-ROW & 10-ROW FINE SEED PLANTER or COVER CROP DISC PLANTER

• Typical use: Cover crops in vineyards or orchards & for planting pastures.

• Rows: 8, 10 (178 mm or 254 mm spacing).

• No Till or Conventional
• Three-point
• 3-Compartment seed bin
• Fertiliser (granular) application with seed


Click here to download PDF...

Click here to view a demonstration video...

No Till or Conventional
TINE PLANTER (GRAVITY FEED)

• Typical use: Grain crops (ex.: wheat, oats), canola, medics & similar seeds

• Hydraulic break-away tines

• Planting width: 3.5 - 5 m wide

• Tine spacing: 275 mm (13-, 15-, 17-, 19-tine)
  or 300 mm (15-, 17-tine)

• Simple, robust & effective design

• Inexpensive & locally obtainable wearing parts

• Accurate seed placement
• Excellent germination & yield results.

• Quick and easy lever calibration


Click here to download PDF...

Click here to view a demonstration video...

8 TON TRANSFER CART

• Typical use: Transfer of grain or corn

• Capacity: 8 ton

• Quick unload time


12 TON TRANSFER CART

• Typical use: Transfer of grain or corn

• Capacity: 12 ton

• Quick unload time
• Low centre of gravity (does not tip over easily)
• Big wheels, low compaction
• Narrow structure
• Low maintainance
• Unload speed adjustable according to seed type
• Sealed off auger allows for transport without extra weight inside of the auger
• Complete unload assured via hydraulic sluice below transfer cart and a sluice at bottom of auger


OFFSET DISC PLOUGH

• 12, 16 or 20 discs

• Disc size: 22"

• Fitted with 3-point frame

• Individual ball-bearings & seals per set

• Each disc is secured with its own nut

• Seed & fertiliser box sold separately (optional)

• Disc gangs can be angled individually to match tractor speed, with working depth controlled through tractor hydraulics, gives maximum penetration and traction.

• Cutaway discs on front gangs enable tough trash to be chopped and turned in quickly and surely.


TANDEM OFFSET DISC PLOUGH

• 16 discs
• Disc spacing: 254 mm
• Planting width: 2.03 m

• Disc size: 22"

• Fitted with 3-point frame

• Individual ball-bearings & seals per set

• Each disc is secured with its own nut

• Disc gangs can be angled individually to match tractor speed, with working depth controlled through tractor hydraulics, gives maximum penetration and traction.

• Cutaway discs on front gangs enable tough trash to be chopped and turned in quickly and surely.


PIKET DAM SCOOP

The trusted Piket Dam Scoop was designed to work primarily with wheel type tractors for making dams, dam walls, and for all kinds of earth moving operations. Two scoops can be coupled in tandem without the need to increase drawbar power, thus doubling the capacity. A great time and effort saver. The scoop is lifted or lowered by two double-action, long-stroke hydraulic cylinders, fitted one each side of the scoop. The Piket Dam Scoop is ruggedly built to last. Specially designed for low-maintenance and efficient operation.

• 4,8 kub meter of soil can be transported in one operation, when hitched in tandem.

• The 12 x 18 x 10 ply size tyres provide good floating in muddy and/or sandy soil. This improves tractor performance.

• Cutting blade width: 1.83 m

• Hydraulic cylinders: 2 x 80 diameter x 457mm stroke.

• Required tractor size: 75 - 80 kW or more.
• (*Product not readily available; there is a lead time of approximately 1 calendar month)

Email us for more information at info@piket.co.za

PIKET LOGSPLITTER

• 457 mm stroke length, with an 80mm diameter heavy-duty cylinder.

• Cylinder has an extra-thick chrome shaft to ensure durability.

• The splitter can split in both directions.

• The splitter is not subject to a great deal of wear.

• The blade does not need sharpening.

• The operator need to handle the wood while it is being split.

• Operational via tractor; or a hydraulic-electric or hydraulic-petrol power source.

• Large blocks are split from the sides to the centre into smaller blocks.

• Able to transport splitter with a tractor's three-point.

• Splits 800 - 1200 pieces per hour on average.

• Flow of oil from the tractor determines the splitter speed.

Email us for more information at info@piket.co.za

PIKET LOGSAW

• 750 mm Tungsten blade

• Blade can be sharpened

• Protection from moving parts

• 3-Point tractor transportation

• Various drives: Tractor-, machine-, and/or electrical drive

Email us for more information at info@piket.co.za

PIKET ARENA LEVEL ROLLER

The horse arena harrow and round bar roller is intended for levelling and loosening horse arena riding surfaces. The harrow will loosen the surface, a leveller that will make the surface completely even and a round bar tilling roller that will compact the ground, leaving a great looking finish to the surface.

• Width: 1.5 m; Length: 2.954 m; Towing action: Drawbar or
• width: 2 m; Length: 3.043 m; Towing action: Drawbar.
• (*Product not readily available; there is a lead time of approximately 1 calendar month)

Email us for more information at info@piket.co.za

14-Row
HYDRAULIC PICK-UP ATTACHMENT

• 14-Rowplanter's hydraulic pick-up attachment


CONCAVES

• Claas / John Deere / Laverda / Massey Ferguson or New Holland
• Typical use: Wheat
